portal, The remains of the timbered 7th level Southwest mine portal located in Uncle Sam Gulch. Rail leaves the caved adit with an old boiler next to it.

press to zoom

Mule shoes found inside the Southwest mine.

press to zoom

Twilight manganese workings located on the Twilight claim. They mined the ore using both open cut and underground mining techniques.

press to zoom

Motor and loaded timber trucks on the 1450 level Cole 1973

press to zoom

Wolf 856 canister lamp, a common type of carbide lamp used underground in Bisbee's mines in the 1910's -1920's.

press to zoom

A view looking down the Queen tunnel.

press to zoom

Junction Hoist in 1963. Richard Graeme III climbing stairs in left photo

press to zoom

A view inside the power plant at the Crawford Mill site. The four large diesel generators are at the back.

press to zoom

Queen rocker located at the intersection of 8 crosscut and 14 crosscut 4th level Southwest mine.

press to zoom

Air door inside the Queen Tunnel.

press to zoom

The various styles of miners brass or man tags used in the Bisbee mines. Tags marked with the specific mine like Spray, Czar etc are ore sample tags and are often thought to be man tags. Hourly employees have their payroll number stamped on the tag. The engineers, geologist. etc have their initials stamped on the tag.

press to zoom

A view from the Copper Queen open cut looking to the surface. Circa 1899

press to zoom

Employee safety recognition awards issued by Phelps Dodge (Copper Queen Branch) during the 1920's and 30's the Items consist of pins, wallet and belt buckle.

press to zoom

Sunrise shaft headframe. An odd design for a headframe, the hoist sits directly above the shaft. The cable leaves the hoist and goes to the cage without using sheave wheels or rollers.

press to zoom

Image showing the wooden brake shoes on the main hoist of the Campbell mine.

press to zoom

Timber station inside 39 XC (crosscut) Queen Tunnel.

press to zoom

Group of miners underground in Bisbee. The man on the far right is Niels Martin Pederson. Collection Mark Pederson. Used with permission

press to zoom

The Denn headframe after the toplanders deck and chutes have been removed.

press to zoom

Trolley sign and trolley hanger on the 3rd level Southwest shaft station. Inside the sign is a knife switch, bulb socket and Edison style light bulb.

press to zoom

A flat cable traction hoist inside the headframe of the Sunrise shaft.

press to zoom

The concrete collar of the Oakland Shaft. located near the intersection of School Terrace road and Highway 92.

press to zoom

Re-timbered 3rd level Southwest shaft station

press to zoom

Shown is the last type of bell chart used in the Bisbee mines. The chart list the bell signals which the cager’s use to communicate with the hoist man to move the cages and skips.

press to zoom

Postcard view of the Junction Mine and mine shops of the Calumet and Arizona Mining Company C – 1920. Graeme Larkin collection.

press to zoom

Typical hand drilling equipment used in the Bisbee mines. Double jack, single jack hammers with steels and a drilling spoon.

press to zoom

A shift of miners at the Junction Shaft prior to entering the mine C – 1925. Graeme Larkin collection

press to zoom

H- Car loaded with timber

press to zoom

Crazy Horse Pete inclined shaft also known as the Divided and/or Merrill shaft. It is located just above the Queen Tunnel portal. The shaft was in existence by 1903, it is double compartment with one being used as a manway and the other for hoisting. At one time the shaft had a small odd looking headframe on it. Last used in the 1940’s by Pete Ivanovich (Crazy Horse Pete) who leased it from Phelps Dodge.

press to zoom

Train of H cars inside Queen tunnel

press to zoom

The concentrator tunnel used as an alternate access yo the lower part of the mill. When in operation you could see electric light bulbs running down the tunnel and there always was a timber truck sitting on the bridge at the entrance.
